Place of Origin:
Brand Name:
Certification:
Delivery Time:
Minimum Order Quantity:
Hong Kong
OEM or ZWD
CE ROHS
2-8 working days
2
| screen size | 23.8inches |
|---|---|
| resolution ratio | 1920(RGB)×1080, FHD |
| Pixel layout | RGB vertical stripe |
| Color Quantity | 16.7Mcolors(8bits) |
| Aspect ratio | 16:9 |
| brightness | 250 cd/㎡(Typ.) |
Contacts：Adeline
Tel:+86 -17765298109
Fax:+86-755-28193671
| Screen parameters | model | ZW238P |
| screen size | 23.8inches | |
| Panel Type | IPS（M238 -IPS280MCD） | |
| resolution ratio | 1920(RGB)×1080, FHD | |
| pixel pitch(W×H） | 0.0915(H)x0.2745(V)mm | |
| Pixel layout | RGB vertical stripe | |
| Color Quantity | 16.7Mcolors(8bits) | |
| Surface Treatment | Anti-Glare,3H | |
| Aspect ratio | 16:9 | |
| brightness | 250 cd/㎡(Typ.) | |
| refresh rate | 100HZ | |
| response time | 5 ms | |
| contrast ratio | 3000:1 | |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) | |
| storage temperature | -20 ~ 60 °C | |
| operation temperature | 0 ~ 50 °C | |
| Appearance Style | Ultra thin black, with built-in bracket | |
| Landscape portrait | Landscape mode | |
| Display Mode | Normally Black | |
| Other | TYPE-C input voltage | Adapter：5V ~ 20V |
| Panel Voltage | 3.3V | |
| Backlight Adjust Type | SW Adjust | |
| Power output specifications | Default DC=5V3A, optional PD=5V3A/9V3A/12V3A/15V3A/20V3.25A | |
| Display function | Key control | 4 keys (power on/off, plus, minus, menu) |
| built-in speaker | Stereo 2.0, 8Ω, 1W * 2 | |
| brightness adjustment | 20-250cd/㎡ PWM dimming | |
| contrast adjustment | Support | |
| Scenario mode switching | Six preset modes | |
| Dynamic Contrast | Change the scene according to the displayed content | |
| Sharpness adjustment | Level 1-4 | |
| Color temperature adjustment | Preset 9300K, 6500K, 5400K, user-defined, default customizable | |
| Color adjustment | Support simultaneous adjustment of RGB | |
| Saturation adjustment | Support | |
| Low blue light adjustment | Levels 1-10 | |
| Color gamut mode selection | Preset 4 modes | |
| Volume Control | Level 0-10 | |
| mute switch | Support | |
| Language Selection | Preset 10 languages | |
| HDR | Support | |
| Free sync | Support | |
| Signal source channel switching | Support switching when inputting simultaneously | |
| Product interface | Fully functional Type-C power supply | 1. Type-C power supply (connected to a power adapter for power supply) |
| Fully functional Type-C power supply | 1. Type-C power supply (connected to a power adapter for power supply) | |
| Mini HDMI | 1. Mini HDMI 2.0 (supports connecting various HDMI devices) | |
| Audio output | Audio 3.5mm standard port (headphone/playback output) | |
| Standard List | power cord | 1 |
| Mini HDMI | 1,(1.5M) |
